Not able to Explore Images when I am not logged into the app.

[vibhusharma101]

Summary:

Not able to Explore Images when I am not logged into the app. This is the same exception which is coming when we are trying to login into the app.

Steps to reproduce:

How can we reproduce the issue?

What did you expect the app to do, and what did you see instead?

I Except the app to show me the images.

System logs:
This is the request string

--D/OkHttp: --> GET https://commons.wikimedia.beta.wmflabs.org/w/api.php?action=query&format=json&formatversion=2&generator=categorymembers&gcmtype=file&gcmsort=timestamp&gcmdir=desc&prop=imageinfo&iiprop=url|extmetadata&iiurlwidth=640&iiextmetadatafilter=DateTime|Categories|GPSLatitude|GPSLongitude|ImageDescription|DateTimeOriginal|Artist|LicenseShortName|LicenseUrl&gcmtitle=Category%3AUploaded_with_Mobile%2FAndroid&gcmlimit=10

This is the logs of the error

E/CategoryImagesListFragment: Error occurred while loading images inside a category
    javax.net.ssl.SSLHandshakeException: Chain validation failed
        at com.android.org.conscrypt.ConscryptFileDescriptorSocket.startHandshake(ConscryptFileDescriptorSocket.java:229)
        at okhttp3.internal.connection.RealConnection.connectTls(RealConnection.kt:351)
        at okhttp3.internal.connection.RealConnection.establishProtocol(RealConnection.kt:310)
        at okhttp3.internal.connection.RealConnection.connect(RealConnection.kt:178)
        at okhttp3.internal.connection.ExchangeFinder.findConnection(ExchangeFinder.kt:236)
        at okhttp3.internal.connection.ExchangeFinder.findHealthyConnection(ExchangeFinder.kt:109)
        at okhttp3.internal.connection.ExchangeFinder.find(ExchangeFinder.kt:77)
        at okhttp3.internal.connection.Transmitter.newExchange$okhttp(Transmitter.kt:162)
        at okhttp3.internal.connection.ConnectInterceptor.intercept(ConnectInterceptor.kt:35)
        at okhttp3.internal.http.RealInterceptorChain.proceed(RealInterceptorChain.kt:112)
        at okhttp3.internal.http.RealInterceptorChain.proceed(RealInterceptorChain.kt:87)
E/CategoryImagesListFragment:     at okhttp3.internal.cache.CacheInterceptor.intercept(CacheInterceptor.kt:82)
        at okhttp3.internal.http.RealInterceptorChain.proceed(RealInterceptorChain.kt:112)
        at okhttp3.internal.http.RealInterceptorChain.proceed(RealInterceptorChain.kt:87)
        at okhttp3.internal.http.BridgeInterceptor.intercept(BridgeInterceptor.kt:84)
        at okhttp3.internal.http.RealInterceptorChain.proceed(RealInterceptorChain.kt:112)
        at okhttp3.internal.http.RetryAndFollowUpInterceptor.intercept(RetryAndFollowUpInterceptor.kt:71)
        at okhttp3.internal.http.RealInterceptorChain.proceed(RealInterceptorChain.kt:112)
        at okhttp3.internal.http.RealInterceptorChain.proceed(RealInterceptorChain.kt:87)
        at fr.free.nrw.commons.OkHttpConnectionFactory$CommonHeaderRequestInterceptor.intercept(OkHttpConnectionFactory.java:56)
        at okhttp3.internal.http.RealInterceptorChain.proceed(RealInterceptorChain.kt:112)
        at okhttp3.internal.http.RealInterceptorChain.proceed(RealInterceptorChain.kt:87)
        at fr.free.nrw.commons.OkHttpConnectionFactory$UnsuccessfulResponseInterceptor.intercept(OkHttpConnectionFactory.java:62)
        at okhttp3.internal.http.RealInterceptorChain.proceed(RealInterceptorChain.kt:112)
        at okhttp3.internal.http.RealInterceptorChain.proceed(RealInterceptorChain.kt:87)
        at okhttp3.logging.HttpLoggingInterceptor.intercept(HttpLoggingInterceptor.kt:215)
        at okhttp3.internal.http.RealInterceptorChain.proceed(RealInterceptorChain.kt:112)
        at okhttp3.internal.http.RealInterceptorChain.proceed(RealInterceptorChain.kt:87)
        at okhttp3.RealCall.getResponseWithInterceptorChain(RealCall.kt:184)
        at okhttp3.RealCall.execute(RealCall.kt:66)
        at retrofit2.OkHttpCall.execute(OkHttpCall.java:180)
        at retrofit2.adapter.rxjava2.CallExecuteObservable.subscribeActual(CallExecuteObservable.java:42)
        at io.reactivex.Observable.subscribe(Observable.java:12090)
        at retrofit2.adapter.rxjava2.BodyObservable.subscribeActual(BodyObservable.java:34)
        at io.reactivex.Observable.subscribe(Observable.java:12090)
        at io.reactivex.internal.operators.observable.ObservableFlatMap.subscribeActual(ObservableFlatMap.java:55)
        at io.reactivex.Observable.subscribe(Observable.java:12090)
        at io.reactivex.internal.operators.observable.ObservableMap.subscribeActual(ObservableMap.java:32)
        at io.reactivex.Observable.subscribe(Observable.java:12090)
        at io.reactivex.internal.operators.observable.ObservableCollectSingle.subscribeActual(ObservableCollectSingle.java:49)
        at io.reactivex.Single.subscribe(Single.java:3438)
        at io.reactivex.internal.operators.single.SingleSubscribeOn$SubscribeOnObserver.run(SingleSubscribeOn.java:89)
        at io.reactivex.Scheduler$DisposeTask.run(Scheduler.java:578)
        at io.reactivex.internal.schedulers.ScheduledRunnable.run(ScheduledRunnable.java:66)
        at io.reactivex.internal.schedulers.ScheduledRunnable.call(ScheduledRunnable.java:57)
        at java.util.concurrent.FutureTask.run(FutureTask.java:266)
        at java.util.concurrent.ScheduledThreadPoolExecutor$ScheduledFutureTask.run(ScheduledThreadPoolExecutor.java:301)
        at java.util.concurrent.ThreadPoolExecutor.runWorker(ThreadPoolExecutor.java:1167)
        at java.util.concurrent.ThreadPoolExecutor$Worker.run(ThreadPoolExecutor.java:641)
        at java.lang.Thread.run(Thread.java:764)
    Caused by: java.security.cert.CertificateException: Chain validation failed
        at com.android.org.conscrypt.TrustManagerImpl.verifyChain(TrustManagerImpl.java:707)
        at com.android.org.conscrypt.TrustManagerImpl.checkTrustedRecursive(TrustManagerImpl.java:539)
        at com.android.org.conscrypt.TrustManagerImpl.checkTrustedRecursive(TrustManagerImpl.java:560)
        at com.android.org.conscrypt.TrustManagerImpl.checkTrustedRecursive(TrustManagerImpl.java:605)
        at com.android.org.conscrypt.TrustManagerImpl.checkTrusted(TrustManagerImpl.java:495)
        at com.android.org.conscrypt.TrustManagerImpl.checkTrusted(TrustManagerImpl.java:418)
        at com.android.org.conscrypt.TrustManagerImpl.getTrustedChainForServer(TrustManagerImpl.java:339)
        at android.security.net.config.NetworkSecurityTrustManager.checkServerTrusted(NetworkSecurityTrustManager.java:94)
        at android.security.net.config.RootTrustManager.checkServerTrusted(RootTrustManager.java:88)
        at com.android.org.conscrypt.Platform.checkServerTrusted(Platform.java:208)
        at com.android.org.conscrypt.ConscryptFileDescriptorSocket.verifyCertificateChain(ConscryptFileDescriptorSocket.java:404)
        at com.android.org.conscrypt.NativeCrypto.SSL_do_handshake(Native Method)
        at com.android.org.conscrypt.NativeSsl.doHandshake(NativeSsl.java:375)
        at com.android.org.conscrypt.ConscryptFileDescriptorSocket.startHandshake(ConscryptFileDescriptorSocket.java:224)
    	... 49 more

Screen-shots:

[vibhusharma101]

@nicolas-raoul @maskaravivek sir please look into this as according to me there is problem with the request string that we are sending to the server, because in login and in this both chain verification error is coming.?

[maskaravivek]

Should be fixed with #3349

[ashishkumar468]

This does not seems to be fixed, #3349 only influences the api calls with the app provided OKHTTP Client
